TH70 |

Tandem Axle, Pipe Top Utility Trailer

TH70

OrangeLine TH70
TH70 Learn More +
Tandem Axle, Pipe Top Utility Trailer
Length 18′ 20′
Width 83″ 83″
GVWR Rating 7,000# 7000#
Empty Weight 1,910# 2,060#
Payload Weight 5,090# 4,940#
Length 18′ | 20′
Width 83”
GVWR Rating 7,000#
Empty Weight 1,910# | 2,060#
Payload Weight 5,090# | 4,940#
Frame 5” x 3” x 5/16” Angle
Cross Members 3” x 2” x 3/16” Angle
Front Stop Rail Square Tubing Front Stop Rail
Coupler Adjustable, 2” Forged Coupler
Jack 2,000# Top Wind, Set-Back Jack w/ Removable Sand Foot
Fenders Removable 9” x 72” Double-Broke Diamond Plate Steel
Axles Dexter Brand, 3,500# Axle w/ EZ Lube Hubs
Brakes Nev-R-Adjust Electric Brakes on All Hubs
Suspension Multi-Leaf Spring w/ Equalizer
Tires ST205/75R-15 Load Range C
Wheels 15” x 5”; White Mod, 5 on 5 Bolt Pattern
Decking 2” Treated Pine
Lights Recessed, L.E.D. D.O.T. Stop, Tail, Turn & Clearance
Electric Plug 7-Way RV Style
Wiring Sealed, Modular Wiring Harness
Ramps 4’ Slide-In Ramps (Side Pockets)
Cargo Control (8) Tie Down Pockets Along Sides
